Digital Thermometer Pewter /Bullet Casting Molten Metal for less then 1000F

$349.00 $299.00
(You save $50.00)
SKU:
DigitalTherm
Availability:
in stock
Weight:
1.00 LBS
Shipping:
Calculated at Checkout
Digital Thermometer  Pewter /Bullet Casting Molten Metal for less then 1000F



RotoMetals Digital Thermometer is a high accuracy thermometer with digital display. It features an IP67/NEMA 4X enclosure and a 5 year battery life. The Digital Thermometer is perfect for a variety of markets and applications where a high accuracy digital readout is required. Has a 4" knuckle then connection with 5" long probe



  • High Accuracy 1,000Ω RTD (Class A, 0.06%)
  • IP67/NEMA 4X
  • 5 Year Battery Life
  • Bottom Connect
  • Low or High Temperature Range Models



These are made to order 1-2 week lead time, and can also be customize shorter or longer stems if needed



Sensing Element RTD, Type Pt1000Ω, Class A
Temperature Ranges  -328°F to 1112°F (-200°C to 600°C)
Accuracy ± ( 0.36 + 0.002 x IT-32I) °F
± ( 0.2 + 0.002 x ITI) °C
Example: At 32°F acccuracy is ± 0.36 °F.
Refresh Rate 3 Seconds
Display ± 1% 4-digit LCD, 1/2” Height
Display Resolution See Table 1
RFI Effect 1% or Less Typical
Temperature Effect <0.01% FS/°C
Ambient Temperature Range 32°F to 122°F (0°C to 50°C)
Storage Temperature Range -4°F to 158°F (-20°C to 70°C)
Housing Material Stainless Steel 316
Lens Glass
Probe Material 304 Stainless Steel
Weight 12 oz., Varies by Configuration
Environmental Protection NEMA 4X/IP67
Power 1 x 3.6V AA Batteries
Battery Life 5 Years Minimum in Continuous Mode
Electronic Display Temperature Limit If the temperature of the electronics in the display housing exceeds 122°F (50°C), permanent damage to the display will occur. A remote mount is recommended for high temperature applications.
